P/N IRFAC12MF
Fitur/Keterangan:
Specifications Chart:
| Model |
Capacity 7 bar g m3/min |
Port Conn BPST |
Dimension (mm) |
WeIAht (kg) | Filter CPN | ||
| A | B | Unit |
Element |
||||
| FA30IA | 0.48 | 3/8" | 76 | 172 | 0.562 | 24356487 | 24356669 |
| FA40IA | 0.62 | 1/2" | 76 | 172 | 0.547 | 24231821 | 24241812 |
| FA75IA | 1.27 | 3/4" | 98 | 227 | 1.069 | 24231912 | 24241861 |
| FA110IA | 1.84 | 3/4" | 129 | 227 | 1.091 | 24232001 | 24241929 |
| FA150IA | 2.49 | 1" | 129 | 266 | 2.063 | 24232076 | 24241986 |
| FA190IA | 3.12 | 1" | 129 | 266 | 2.063 | 24232159 | 24242059 |
| FA230IA | 3.82 | 1" | 129 | 266 | 2.063 | 24232233 | 24242117 |
| FA400IA | 6.66 | 1 1/2" | 129 | 356 | 2.361 | 24232316 | 24242174 |
| FA490IA | 8.21 | 1 1/2" | 170 | 356 | 2.361 | 24232407 | 24242240 |
| FA600IA | 9.91 | 2" | 170 | 465 | 5.196 | 24232480 | 24242281 |
| FA800IA | 13.31 | 2" | 170 | 465 | 5.238 | 24232563 | 24242323 |
| FA1000IA | 16.99 | 2" | 205 | 465 | 5.257 | 24232647 | 24242364 |
| FA120IA | 20.11 | 3" | 205 | 547 | 9.307 | 24232720 | 24242406 |
| FA1560IA | 26.05 | 3" | 205 | 647 | 10.694 | 24232803 | 24242448 |
| FA1830IA | 30.59 | 3" | 205 | 647 | 10.694 | 24232886 | 24242489 |
| FA2300IA | 38.23 | 3" | 205 | 877 | 13.696 | 24232969 | 24242521 |
| FA2700IA | 45.31 | 3" | 205 | 877 | 13.696 | 24233041 | 24242562 |
Operating Limitations:
- Maximum operating pressure: 17.2 bar (g)
- Maximum operating temperature 30 °C
- Minimum operating temperature 1 °C
Spesifikasi:
Option parts:
| Model |
Ring Set CPN |
Differential Gauge (BPST) CPN |
Clamp Kit CPN |
Bracket Kit CPN |
| F30I | 24356701 | 24356750 | 24361917 | 24361966 |
| F40I | 24334930 | 24356750 | 24361917 | 24361966 |
| F75I-F11I | 24334955 | 24335044 | 24361925 | 24361974 |
| F150I-F230I | 24334963 | 24335044 | 24361933 | 24361982 |
| F400I-F490I | 24334971 | 24335044 | 24361933 | 24361982 |
| F600I-F1000I | 24334989 | 24335044 | 24361941 | 24361990 |
| F1200I | 24334997 | 24335044 | 24361958 | 24362006 |
| F1560I-F1830I | 24335002 | 24335044 | 24361958 | 24362006 |
| F2300I-F2700I | 24335010 | 24335044 | 24361958 | 24362006 |
Note:
- 24335028 AUTO DRAIN F Series
- 24335036 MANUAL DRAIN F Series
Product Descriptions:
- Air quality to ISO 8573.1:2010/Class 1 oil
- Oil vapor and hydrocarbon odor removal at 21 °C
- Maximum remaining oil content of < 0.03 mg/m3
- Compliance with PED 97/23EC and CE
- Standard filters include gauge and 1/2" F Manual Valve
