Herman Industries EU-2000 High-speed Bridge-type Double Column Machining Center
P/N LKEU2000
Fitur/Keterangan:
TC Series Tapping Center Product Specifications:
| Specifications | EU-2000 |
|---|
| X-axis Travel |
2000 |
| Y-axis Travel |
1250 |
| Z-axis Travel |
650 |
| Distance from spindle center to table surface (mm) |
150-800 |
| Table dimension (mm) |
2300 x 1000 |
| Max. table load (kgs) |
2500 |
| Rapid traverse (m/min) |
30/30/30 |
| Cutting feedrate (m/min) |
10 |
| Spindle speed (rpm) |
18000 |
| Spindle nose |
HSK-A63 |
| Spindle motor (kw) |
46 |
| Tool changer |
24 Umbrella |
| Machine dimension (mm) |
7000 x 3750 x 4400 |
| Machine weight (kgs) |
19000
|
Spesifikasi:
Features:
- High-speed Bridge-type Double Column Machining Center
- For machining industries in 3C parts (Machining example): Mini Projection Chip, Tablet Back Cover – internal (iPad), Tablet back cover – external (iPad), Camera Lens Sleeve, Hard Disk
