P/N D600IN-A
Fitur/Keterangan:
Model |
Capacity m3/min PDP |
Nominal Power (kW) |
Max Op Pressure bar (g) |
Dimensions | Weight |
Std Power Supply V/Ph/Hz |
|||
| 7°C | 3°C | Length(mm) | Width (mm) | Height (mm) | |||||
| D600IN-A | 12.0 | 10.00 | 1.85 | 14 | 720 | 750 | 1350 | 120 | 230/1/50 |
| D780IN-A | 15.60 | 13.00 | 1.98 | 12 | 720 | 750 | 1425 | 130 | 400/3/50 |
| D950IN-A | 19.00 | 15.83 | 2.58 | 12 | 720 | 750 | 1425 | 150 | 400/3/50 |
Performance based on:
- Ambient Pressure equal to 1 bar g
- Ambient temperature equal to 25 °C
- Dyer inlet air relative humidity 100%
- Dyer inlet pressure equal to 7 bar g
- Dyer inlet temperature equal to 35 °C
Operating limitations:
- Ambient: Min 2 °C, Max 50 °C (D600IN-A-D950IN-A)
- Air inlet temperature Max 60 °C
Spesifikasi:
Product Descriptions:
- Air cooled R507a, 3 in 1 Low Pressure Drop Aluminium heat exchanger
- Stainless Steel Demister / High Efficiency Condenser
- Anti-freezing/energy saving function
- Electronic No Loss Drain (ENLD) as Standard
- History of latest 10 alarms (D600IN-A to D950IN-A)
- Heat resistant to corrosion, reduce barriers to air flow for more efficient throughput and less energy
- Variable speed fans
- Programmable electronic drain valve
