John Bean B9100 Wheel Balancer with LED Display

P/N B9100
John Bean B9100 Wheel Balancer with LED Display
Fitur/Keterangan:
TECHNICAL DATA

Rim centre bore diameter (mm)                               43 - 116
Shaft diameter (mm) 40
Measuring speed (rpm) 200
Measuring time (s) 7
Display / Monitor                                                                LED
Rim width (Inch) 3 - 16
Rim diameter - manual input (Inch) 12 - 22
Wheel width max. (mm) 500
Wheel diameter max. (mm) 880
Wheel weight max. (kg) 65
Input of distance machine / rim flange                                    manual
Input of rim diameter                                                           manual
Input of rim width                                                               manual
Power supply                                                                     200-240 VAC 1 ph 50/60Hz
Dimensions - Width (mm) 1036
Dimensions - Depth (mm) 1111
Dimensions - Height (mm) 1633
Machine weight (kg) 70
Noise level (dB (A)) <70
Spesifikasi:

John Bean B9100 Wheel Balancer with LE Display

The perfect entry-level wheel balancer for shops desiring to expand into wheel service and looking for value without compromising balancing features.

Key Features

 * Conspicuous LED display integrated in weight tray
 * Manual data input
 * Static and dynamic unbalance measurement in a single measuring run
 * RPI technology (Real Plane Imaging)
 * 6 balancing modes, 5 of which for alloy wheels
 * Spoke mode with hidden weight function
 * Optimisation mode
 * Compact footprint for minimum space requirement
 * Textured surface finish for durability
 * Standard accessories: Wheel guard, 3 centring cones 48-128 mm dia., quick-clamping nut, clamping head with ring and protector, compression spring, rim width callipers, universal weight pliers, 3 storage pegs on the left-hand machine side, calibration weight
