Fitur/Keterangan:
ASME(MOM) + IE1 standard Fan & Main Motor main features:
|
MODEL |
CCN |
CAPACITY |
Operating bar(g) |
Pressure psi(g) |
Cooler |
Voltage (V) |
|
| m3/min | ft3/min | ||||||
|
R90IE_A7.5 |
46863874 |
18.01 |
636 |
7.5 |
110 |
AC |
380-415V/3PH/50HZ |
|
R90IE_W7.5 |
46863916 |
18.01 |
636 |
7.5 |
110 |
WC |
380-415V/3PH/50HZ |
|
R90IE_A8.5 |
46863882 |
17.50 |
618 |
8.5 |
125 |
AC |
380-415V/3PH/50HZ |
|
R90IE_W8.5 |
46863924 |
17.50 |
618 |
8.5 |
125 |
WC |
380-415V/3PH/50HZ |
|
R90IE_A10 |
46863890 |
15.43 |
545 |
10.0 |
145 |
AC |
380-415V/3PH/50HZ |
|
R90IE_W10 |
46863932 |
15.43 |
545 |
10.0 |
145 |
WC |
380-415V/3PH/50HZ |
|
R90IE_A14 |
46863908 |
13.03 |
460 |
14.0 |
200 |
AC |
380-415V/3PH/50HZ |
|
R90IE_W14 |
46863940 |
13.03 |
460 |
14.0 |
200 |
WC |
380-415V/3PH/50HZ |
|
R110IE_A7.5 |
46863957 |
22.09 |
780 |
7.5 |
110 |
AC |
380-415V/3PH/50HZ |
|
R110IE_W7.5 |
46863999 |
22.09 |
780 |
7.5 |
110 |
WC |
380-415V/3PH/50HZ |
|
R110IE_A8.5 |
46863965 |
20.39 |
720 |
8.5 |
125 |
AC |
380-415V/3PH/50HZ |
|
R110IE_W8.5 |
46864005 |
20.39 |
720 |
8.5 |
125 |
WC |
380-415V/3PH/50HZ |
|
R110IE_A10 |
46863973 |
18.89 |
667 |
10.0 |
145 |
AC |
380-415V/3PH/50HZ |
|
R110IE_W10 |
46864013 |
18.89 |
667 |
10.0 |
145 |
WC |
380-415V/3PH/50HZ |
|
R110IE_A14 |
46863981 |
15.40 |
544 |
14.0 |
200 |
AC |
380-415V/3PH/50HZ |
|
R110IE_W14 |
46864021 |
15.40 |
544 |
14.0 |
200 |
WC |
380-415V/3PH/50HZ |
|
R132IE_A7.5 |
46862074 |
26.19 |
925 |
7.5 |
110 |
AC |
380-415V/3PH/50HZ |
|
R132IE_W7.5 |
46862116 |
26.19 |
925 |
7.5 |
110 |
WC |
380-415V/3PH/50HZ |
|
R132IE_A8.5 |
46862082 |
25.34 |
895 |
8.5 |
125 |
AC |
380-415V/3PH/50HZ |
|
R132IE_W8.5 |
46862124 |
25.34 |
895 |
8.5 |
125 |
WC |
380-415V/3PH/50HZ |
|
R132IE_A10 |
46862090 |
22.79 |
805 |
10.0 |
145 |
AC |
380-415V/3PH/50HZ |
|
R132IE_W10 |
46862132 |
22.79 |
805 |
10.0 |
145 |
WC |
380-415V/3PH/50HZ |
|
R132IE_A14 |
46862108 |
18.35 |
648 |
14.0 |
200 |
AC |
380-415V/3PH/50HZ |
|
R132IE_W14 |
46862140 |
18.35 |
648 |
14.0 |
200 |
WC |
380-415V/3PH/50HZ |
Dimensions (mm):
- 2855 L x 1836 W x 2032 H
Max Weight (kg):
- Air cooled 3198 Kg
- Water cooled 3175 Kg
Spesifikasi:
Main features:
- Robust Cast Iron IP55, 380V ~ 415V/3PH/50HZ motor
- Rugged Ingersoll Rand airend with duplex tapered roller bearings
- No maintenance integral gear drive system
- Air or Water-Cooled aftercooler with condensate separator
- Integral star delta starter
- Factory-fill of Ingersoll Rand UltraCoolant
- IntellisysTM SGv capacity control system featuring:
- Sequence up to 4 machines
- On-Line/Off-line control with automatic start & stop
- 15 event history record
- NEMA4 (IP65) Electrical Cabinet
- 75 dB(A) AC / 72 dB(A) WC low sound enclosure
