Ingersoll Rand Modular Desiccant Dryers D41IM and Above with Class 1 Dew Point

P/N IRD-70PDPM
Ingersoll Rand Modular Desiccant Dryers D41IM and Above with Class 1 Dew Point
Fitur/Keterangan:

Specifications Chart:


Model

Capacity m3/min

PDP

Max Op

Pressure bar (g)

 Dimensions  Weight

Std Power

Supply V/Ph/Hz
7°C 3°C Length(mm) Width (mm) Height (mm)
D41IM 28.7 0.48 16 302 284 837 32 230/1/50
D54IM 37.80 0.63 16 302 284 1003 37 230/1/50
D71IM 49.70 0.83 16 302 284 1168 42 230/1/50
D90IM 63.00 1.05 16 302 284 1333 47 230/1/50
D110IM 77.00 1.28 16 302 284 1499 52 230/1/50
D150IM 105.00 1.75 16 302 284 1747 60 230/1/50
D180IM 126.00 2.10 13 566 220 1433 80 230/1/50
D221IM 154.70 2.58 13 566 220 1599 90 230/1/50
D299IM 209.30 3.49 13 566 220 1847 104 230/1/50


Performance based on:

  • Ambient Pressure equal to 1 bar g
  • Ambient temperature equal to 25 °C
  • Dyer inlet air relative humidity 100%
  • Dyer inlet pressure equal to 7 bar g
  • Dyer inlet temperature equal to 35 °C

Operating limitations:

  • Ambient: Min 2 °C, Max 50 °C
Spesifikasi:
  • Air quality to -40 °C ISO 8573 class 2 dew point performance
  • Optional ISO 8573 class 1 dew point performance availale
  • Filtration provided as standard (Filters shipped loose on models D41IM and above)
  • Electronic control panel: D5IM-D34IM easy to read user interface D41M-D299IM interface with functionality wich allow also shows tower pressure gauges
  • Low noise levels for point of use application


IR Compressor, Modular Desiccant Dryers 41IM and above
Filter modul untuk Kompresor IR (Ingersoll Rand), 230V/50 Hz, didesain secara khusus untuk mengurangi ataupun meredam suara/noise
