Categories:
Fitur/Keterangan:
Performance data and dimensions:
|
|
KW |
m3/min |
ft3/min |
bar(g) |
psi(g) |
V |
Tank |
|
|
Base Mounted |
|
|
|
|
|
|
|
|
|
R5IU - A7 |
19005396 |
5.5 |
0.83 |
29.3 |
7 |
102 |
380 / 415 |
W/O |
|
R5IU - A8 |
19005404 |
5.5 |
0.78 |
27.5 |
8 |
116 |
380 / 415 |
W/O |
|
R5IU - A10 |
19005412 |
5.5 |
0.7 |
24.7 |
10 |
145 |
380 / 415 |
W/O |
|
R7IU - A7 |
19005362 |
7.5 |
1.1 |
38.8 |
7 |
102 |
380 / 415 |
W/O |
|
R7IU - A8 |
19005370 |
7.5 |
1.03 |
36.3 |
8 |
116 |
380 / 415 |
W/O |
|
R7IU - A10 |
19005388 |
7.5 |
0.91 |
32.1 |
10 |
145 |
380 / 415 |
W/O |
|
R11IU - A7 |
19005339 |
11 |
1.63 |
57.5 |
7 |
102 |
380 / 415 |
W/O |
|
R11IU - A8 |
19005347 |
11 |
1.52 |
53.6 |
8 |
116 |
380 / 415 |
W/O |
|
R11IU - A10 |
19005354 |
11 |
1.35 |
47.6 |
10 |
145 |
380 / 415 |
W/O |
|
272L ASME Mounted |
|
|
|
|
|
|
|
|
|
R5IU - A7 - X272H |
19012889 |
5.5 |
0.83 |
29.3 |
7 |
102 |
380 / 415 |
272L |
|
R5IU - A8 - X272H |
19012897 |
5.5 |
0.78 |
27.5 |
8 |
116 |
380 / 415 |
272L |
|
R5IU - A10 - X272H |
19012905 |
5.5 |
0.7 |
24.7 |
10 |
145 |
380 / 415 |
272L |
|
R7IU - A7 - X272H |
19012855 |
7.5 |
1.1 |
38.8 |
7 |
102 |
380 / 415 |
272L |
|
R7IU - A8 - X272H |
19012863 |
7.5 |
1.03 |
36.3 |
8 |
116 |
380 / 415 |
272L |
|
R7IU - A10 - X272H |
19012871 |
7.5 |
0.91 |
32.1 |
10 |
145 |
380 / 415 |
272L |
|
R11IU - A7 - X272H |
19012822 |
11 |
1.63 |
57.5 |
7 |
102 |
380 / 415 |
272L |
|
R11IU - A8 - X272H |
19012830 |
11 |
1.52 |
53.6 |
8 |
116 |
380 / 415 |
272L |
|
R11IU - A10 - X272H |
19012848 |
11 |
1.35 |
47.6 |
10 |
145 |
380 / 415 |
272L |
|
272L GB Mounted |
|
|
|
|
|
|
|
|
|
R5IU - A8 - X272H |
19015577 |
5.5 |
0.78 |
27.5 |
8 |
116 |
400v/3ph/50hz |
272L |
|
R5IU - A10 - X272H |
19015585 |
5.5 |
0.7 |
24.7 |
10 |
145 |
400v/3ph/50hz |
272L |
|
R7IU - A8 - X272H |
19015593 |
7.5 |
1.03 |
36.3 |
8 |
116 |
400v/3ph/50hz |
272L |
|
R7IU - A10 - X272H |
19015601 |
7.5 |
0.91 |
32.1 |
10 |
145 |
400v/3ph/50hz |
272L |
|
R11IU - A8 - X272H |
19015619 |
11 |
1.52 |
53.6 |
8 |
116 |
400v/3ph/50hz |
272L |
|
R11IU - A10 - X272H |
19015627 |
11 |
1.35 |
47.6 |
10 |
145 |
400v/3ph/50hz |
272L |
Dimensions (mm) and weight (kg):
- Without air tank: 826L×759W×782H, 280kg
- With 272L air tank :1437L×763W×1433H, 397kg
Spesifikasi:
Air-cooled design with 46℃ ambient continuous-duty rating
- Integrated modular airend with duplex tapered roller bearings
- 400v/3ph/50hz IP55 TEFC motor *
- Star-delta starter
- Automatic stop/start control & Constant Speed control
- Electro-Pneumatic controller
- Hot/ Cold Box Technology
- Rounded edges and no screws protruding design
- Low sound enclosure (72 dBA)
- Poly-V belt drive with easy belt tension control
- Ultra coolant with 2,000 hour serivce schedule
- 8,000 hour/ 2 year coolant change intervals
