Ingersoll Rand 2 Stage Small Recipt Non-Lubricated Air Compressor Standard Package

P/N IR2SST30

Model	CCN	Power KW	Capacity m3/min ft3/min		Operating Pressure bar(g) psi(g)		Motor	Dimensions (mm) L×W×H	Weight Kg	Air Tank Litre
STANDARD PACKAGE-175psig
2340XB3/12	15837800	2.2	0.27	9.6	12.3	175	380- 415V/3ph/50hz	900L×471W×490H	110kg	W/O
2340XB5/12	15837818	4.1	0.38	13.2	12.3	175	380- 415V/3ph/50hz	950L×560W×540H	146kg	W/O
2475XB5/12	15837735	4.1	0.48	17.1	12.3	175	380- 415V/3ph/50hz	985LX530WX570H	135kg	W/O
2475XB7/12	15837743	5.6	0.61	21.5	12.3	175	380- 415V/3ph/50hz	1040LX530WX570H	140kg	W/O
2545XB7/12	15837784	5.6	0.70	24.7	12.3	175	380- 415V/3ph/50hz	1080L×740W×630H	205kg	W/O
2545XB10/12	15837792	7.5	0.97	34.0	12.3	175	380- 415V/3ph/50hz	1080L×740W×630H	221kg	W/O
7100XB15/12	15837727	11.2	1.30	46.7	12.3	175	380- 415V/3ph/50hz	1260L×780W×770H	298kg	W/O
3000XB20/12	15837693	14.9	1.89	66.7	12.3	175	380- 415V/3ph/50hz	1370L×850W×920H	435kg	W/O
3000XB25/12	15837701	18.5	2.40	84.5	12.3	175	380- 415V/3ph/50hz	1370L×850W×920H	468kg	W/O
3000XB30/12	15837719	22.4	2.69	94.9	12.3	175	380- 415V/3ph/50hz	1370L×850W×920H	485kg	W/O

Model	CCN	Power KW	Capacity m3/min ft3/min		Operating Pressure bar(g) psi(g)		Motor	Dimensions (mm) L×W×H	Weight Kg	Air Tank Litre
H2340XB3/18	15837404	2.2	0.25	8.9	17.6	250	380- 415V/3ph/50hz	900L×470W×490H	110kg	W/O
H2475XB5/18	15837412	4.1	0.40	14.1	17.6	250	380- 415V/3ph/50hz	950L×560W×540H	146kg	W/O
H2545XB7/18	15837420	5.6	0.54	19.0	17.6	250	380- 415V/3ph/50hz	1080L×740W×630H	205kg	W/O
H7100XB10/18	15837438	7.5	0.93	32.8	17.6	250	380- 415V/3ph/50hz	1260L×780W×770H	298kg	W/O
H15TXB15/18	15837446	11.2	1.30	46.0	17.6	250	380- 415V/3ph/50hz	1370L×850W×920H	405kg	W/O
H15TXB20/18	15837453	14.9	1.64	58.0	17.6	250	380- 415V/3ph/50hz	1370L×850W×920H	435kg	W/O

Model	CCN	Power KW	Capacity m3/min ft3/min		Operating Pressure bar(g) psi(g)		Motor	Dimensions (mm) L×W×H	Weight Kg	Air Tank Litre
2340XD3/12	15837552	2.2	0.27	9.6	12.3	175	380- 415V/3ph/50hz	870Lx490Wx535H	109kg	W/O
2340XDV3/12	15837560	2.2	0.27	9.6	12.3	175	380- 415V/3ph/50hz	870Lx490Wx535H	98kg	W/O
2340XD5/12	15837826	4.1	0.38	13.2	12.3	175	380- 415V/3ph/50hz	870Lx490Wx535H	110kg	W/O
2340XDV5/12	15837925	4.1	0.38	13.2	12.3	175	380- 415V/3ph/50hz	870Lx490Wx535H	101kg	W/O
2475XD5/12	15837594	4.1	0.48	17.1	12.3	175	380- 415V/3ph/50hz	1040Lx530Wx570H	130kg	W/O
2475XDV5/12	15837602	4.1	0.48	17.1	12.3	175	380- 415V/3ph/50hz	930Lx530Wx570H	130kg	W/O
2475XD7/12	15837768	5.6	0.61	21.5	12.3	175	380- 415V/3ph/50hz	1040Lx530Wx570H	140kg	W/O
2475XDV7/12	15837776	5.6	0.61	21.5	12.3	175	380- 415V/3ph/50hz	930Lx530Wx570H	140kg	W/O
2545XD7/12	15837610	5.6	0.70	24.7	12.3	175	380- 415V/3ph/50hz	1035Lx681Wx684H	221kg	W/O
2545XDV7/12	15837636	5.6	0.70	24.7	12.3	175	380- 415V/3ph/50hz	1035Lx681Wx684H	221kg	W/O
2545XD10/12	15837628	7.5	0.97	34.0	12.3	175	380- 415V/3ph/50hz	1035Lx681Wx684H	229kg	W/O
2545XD10/12SD	15842107	7.5	0.97	34.0	12.3	175	380- 415V/3ph/50hz	1035Lx681Wx684H	229kg	W/O
2545XDV10/12	15837644	7.5	0.97	34.0	12.3	175	380- 415V/3ph/50hz	1035Lx681Wx684H	229kg	W/O

Main Features and advantages of Type 30:

Regulation: Auto Stop/Start, 2340 thru 2545 series, H2340 thru H15T series
Constant speed; 7100 thru 3000
Centrifugal unloader for no load start on 2545, 7100, 3000 & H15T series, prevents motor from starting under load. Eliminates possibility of motor burn out
100% cast icon frame and separately-cast cylinders
Precison machined high quality cast iron cylinders with deep radial fins, suitable for heavy duty operation and longer life
Heat treated stainles steel finger valve assemby, provides a large flow are resulting in lesser heat and carbon build-up. Easy removal & servicing
Efficient finned intercooler tubes.
Runs cooler, resulting in a more efficient compressor that consumes lesser power and lasts longer
Balanced overhung crankshaft
Precision balanced for smooth running with replaceable crankpin bushing that protects the crankshaft from damage
Rugged one-piece connecting rod
Solid-end precision type. No bolts or nuts which can come loose
Factory-filled syntetic lubricants, reduces carbon buildup, extends lubricant change period. Improves compressor performance and life span

What do you get from a Standard Package?

Heavy duty cast iron pump
Efficient electric motor; built-in thermal relay (single phase), TEFC IP54 protection, Clss Finsulation (Three phase)
Highly reliable magnetic starter; direct-on-line (3hp - 10hp), Star Delta (15hp - 30hp)
Time proven parts and components
Totally enclosed wired beltguard
ASME coded air receiver with 3rd party certification
