P/N WC67Y100T
Fitur/Keterangan:
Houmann WC67Y 100T/3200 Technical Parameters:
| SPECIFICATION | UNIT |
| Nominal Force of The Ram | 1000 |
| Working Table Distance | 3200 |
| Upright Column Distance | 2500 |
| Throat Depth | 320 |
| Max Stroke of The Ram | 150 |
| Max Open Height Between the Table and Ram (kN) | 330 |
| Gear Pump (L/min) | 25 |
| Main Motor: | |
| Type | Y132M-4 |
| Power (kW) | 7.5 |
| Speed (r/min) | 1440 |
| Speed for The Ram Stroke: | |
| Empty Stroke | 60 |
| Working Stroke | 6 |
| Return Stroke | 40 |
| Dimension: | |
| Length (mm) | 3300 |
| Width (mm | 1400 |
| Height (mm) | 2380 |
Spesifikasi:
Conventional Hydraulic Press Brake Model WC67Y 100T/3200:
- Adopt integrated hydraulic control system, more reliable and easy for maintenance.
- Hydraulic top-drive, stepless pressure adjustment and high quality sealing rings imported from overseas to ensure the machine tools reliability.
- High accuracy and high strength and can be transported easily
- Protective fence and the safety interlock to ensure the operation safety. Have a movable single-hand pedal switch,easy to operate
- Steel fabricated structure which is duly stress relieved by way of Annealing to ensure the operational accuracies of the machine for longer periods of time.
- Upper stroke design for bending,low noise,stable operating situation
- Mechanical synchronous mechanism and the complex compensation are designed so as to ensure the accuracies of the bent parts (the convex structure for the table above 160T) productivity since set-up times are drastically reduced.
- Inch, single, continuous operation mode being designed for the machine and reversing and maintain time can be controlled by the time relays
- Safety fence and the electric interlocker have been designed for the machine to ensure the operation safety.
