P/N HI712G-912B
Fitur/Keterangan:
| Unit/Model | HI-712G | HI-912G | HI-912B | |
| Capacity | Circular at 90° (mm) | 178 | 299 | 299 |
| Rectangular at 90° (mm) | 178x305 | 178x305 | 178x305 | |
| Circular at 45° (mm) | 127 | 150 | 150 | |
| Rectagular at 45° (mm) | 120x115 | 127x150 | 127x150 | |
| Blade Speed | 60Hz (mpm) | 34, 70, 104 | 37, 78, 115 | 32, 60, 88, 115 |
| 50Hz (mpm) | 29, 59, 87 | 31, 65, 95 | 26, 50, 73, 95 | |
| Motor Power | 750W 1HP (3PH), 1.1 kW/1.5HP (1PH) | 750W 1 HP (3PH)/1.5 kW 2HP (1PH) | 750W 1 HP (3PH)/1.5 kW 2HP (1PH) | |
| Drive | Gear | Gear | V-Belt | |
| Packing Size (cm) | 129x54x115 | 158x62x115 | 154x59x115 | |
| N.W/G.W (kg) | 170/194 | 220/250 | 230/260 | |
Spesifikasi:
- The saw bow with locking handle can be rotated from 0° to 45° the band saw can be used both vertically and horizontally.
- The falling speed of saw bow is controlled by hydraulic cylinder, can be move freely.
- Equipped with a sizing device (the machine will automatically stop after sawing the materials).
- The band saw has a power break protection device (the machine will automatically power off when the rear protective cover is opened).
- The cooling system can prolong the service life of saw blade and improve the precision of workpiece.
- Equipped with a block feeder (with fixed sawing length)
