P/N DW713
Fitur/Keterangan:
| Power Input | 1,600W |
| No Load Speed | 5,000rpm |
| Blade Diameter | 250mm |
| Bevel Capacity | 48"/-3" |
| Miter Capactity (right/left) | 50"/50" |
| Max. Cutting Capacity (WxH) At 90/90 °C | 95x89mm/162x41mm |
| Max. Cutting Capacity (WxH) At 45/90 °C | 67x89mm/114x41mm |
| Max. Cutting Capacity (WxH) At 90/45 °C | 95x61mm/162x2.5mm |
| Max. Cutting Capacity (WxH) At 45/45 °C | 114x25mm |
| Max. Depth of Cut (Saws) | 89mm |
| Weight | 13.6Kg |
| Depth x Length x Height | 620x510x570mm |
Spesifikasi:
- 15 Amp, 5,000 rpm motor delivers extended power and durability
- Stainless steel detent plate with 11 positive stops provides repeatable accuracy and jobsite duability
- Tall sliding fences support crown molding vertically 4-1/2" and easily slides out of the way for bevel cuts
- Machined base fence support maintains fence perpendicularity with blade for cutting accuracy
- Cam miter lock for quick and accurate miter table positioning
- Miter detent override for fine adjustment and precise miter angles
- 0-50° left and right miter capacity for greater versatility
- Bevels 3°-48° for increased cut capacity
- Lightweight (35lbs), built-in carrying handle for increased portability
